GENERAL

     Maximum Pressures............Refer to Pressure Range Table
     Media Compativility..........Air and Liguid,gases
     Pressure Range...............0 to 5000PSI Equivalent
   ELECTRICAL

     Power Supply.................Ext.12-35VDC 2, 4wire
                                  18-26VAC 4 wire
     Connection...................4 screw terminal block
     Output Signal................4-20 mA DC(limited at 30mA DC)
     Loop Resistance..............0-1100 ohms(MAX 35VDC)
     Warm-up Time.................10 minutes
     Display......................3 1/2 digit LCD


   PERFORMANCE AT 23℃

     Zero Output..................4 mA
     Full Span Output.............20 mA
     Accuracy...................±0.25% FS(Includes Linearity,
                                   Hysteresis & Repeatability)
     Operating Temperature........-10℃ ~ +70℃

   MECHANICAL

     Span and Zero Adjustments....Multi-turn potentiometers
     Pressure Connections.........1/8",1/4", 3/8", 1/2 PT male
     Materials....................Aluminum Case,Connection S316
