PHYSICAL DATA

Relative Humidity Range:     0 - 100%
Rh Accuracy:     ± 2% (10 - 90% Rh), ± 3% (0 - 10% and 90 - 100% Rh)
Operating Temperature Range:     32 to 158°F (0 to 70°C)
Temperature Measurement Range:     32 to 212°F (0 to 100°C)
Temperature Accuracy:     ± 1°F (0.5°C)
Output:     2 channels, each 4 - 20 mA, loop powered on Rh channel
Power Supply:     10 - 35 VDC
Ambient Operating Temperature Limits:     32 to 158°F (0 to 70°C)
Storage Temperature Limits:     -40 to 176°F (-40 to 80°C)
Housing:     ABS plastic
Sensor Probe:     5/16" x 10" (0.8 x 25.4 cm) stainless steel
Cable Length:     48 inches (1.22 meters)
Weight:     5.5 oz (156 gr)

STOCKED MODELS............................
657-1 RH/Temperature Transmitter..........
NO.A-158 spit Flange Mounting Kit.........
NO.A-159 Duct Mounting Gland..............
