PHYSICAL DATA

MEDIA: Air, nitrogen, or non-corrosive, non-combustable gases.




ACCURACY: ± 1% FS.




REPEATABLITY: ± 0.2% full scale.




RESPONSE TIME: 0.1 seconds to 63% of final velocity value.




FLOW RANGE ADJUSTMENT: 50 to 100% FS.




TIME RESPONSE: Adjustable 1s to 7s.




CORRECTION FACTOR SETTING: 0.5 to 2.




GAS PRESSURE: 150 psig (10 bar) max.




GAS TEMPERATURE: -40 to 250°F (-40 to 120°C).




SUPPLY VOLTAGE: 18 to 30 VDC, 625 mA max.




OUTPUT: 4 to 20 mA linear, optical/galvanic isolated; proportional to point
mass flow rate or velocity.




LOAD RESISTANCE: 700 Ohm max.




RELAY RATING: Maximum 42 VAC/VDC, 140 mA.




AMBIENT TEMPERATURE RANGE: 32 to 122°F (0 to 50°C).




COMPUTER REQUIREMENTS: IBM compatible 386 or above and Windows 95
or later with minimum 8 mB RAM (16 mB preferred) and one serial port.




WETTED PARTS: 304 SS probe, glass filled polyester sensor, epoxy, and ceramic.




HOUSING: NEMA 4X (IP65) powdercoated cast aluminum.




ELECTRICAL CONNECTION: 1/2" NPT(F).




MOUNTING: 3/8" tube compression fitting (not included).




WEIGHT: 0.7 lbs (0.30 kg).
