PHYSICAL DATA
Ambient Temperature: 20 to 120°F. (-6.7 to 49°C) Low temperature option
available.
Rated Pressure: -20" Hg. to 25 psig (-.67 to 1.7 bar). MP option; 35 psig (2.4
bar), HP option; 80 psig (5.5 bar). 36003S-36010S; 150 psig (10.3 bar). 36020S
and higher; 1.5 x full scale pressure.
Accuracy: ±2% of full scale at 70°F (21 .1°C). 3% on -0 and 4% on -00 models.
Gage Connections: 1/8" NPT(F).
Power Required: 120 VAC, 50/60 Hz
Electrical Rating of Relays: 10 A @ 120 VAC, 6 A @ 240 VAC, 60 Hz res.
Conduit Opening: ¾" conduit.
Finish: Dark gray
Weight: Photohelic, 4 lbs. (1.8 kg). Use with air or compatible gases only.
|
