PHYSICAL DATA

Input:     7.5 VDC max. pulse
Accuracy:     ±0.2%
Input Impedance:     27 k at 3BDC
Totalizer Type:     UP count
Rate Indication Type:     Frequency
Count Input Speed:     10 kHz @ 50% duty cycle
Totalizing Range:     0.0001 to 100.0000 with five position decimal point
Rate Indication Range:     .001 to 9999 (five position decimal point)
Update Time:     0.7 seconds
Display:     8-digit LCD, 7/16" H
Operating Temperature Range:     32 to 131°F (0 to 55°C)
Housing Material:     Cycolac X-17
Power:     One 3V lithium battery (included)

STOCKED MODELS
TM2............................................
Accessory
TM25,Replacement 3V lithium battery............
