PHYSICAL DATA

Adjustable Range:
    400 - 1600 FPM
(300 - 1600 with vane vertical, pointing up)

 Electrical:

½" HP:


    125 VAC - 9.8 amp full load
           58.8 amp locked rotor
250 VAC - 4.9 amp full load
           29.4 amp locked rotor
Pitot Duty Rating:  470 VA at 125, 250 VAC
Resistive:  15 amp at 125, 250, or 480 VAC

Temperature:
    Maximum 180°F (82°C)

Wiring Connections:
    3 screw type; common, normally open and normally closed

Conduit Connection:
    ½" NPT female

Housing:
    Aluminum die casting with chemical conversion coating for corrosion protection; steel stamping, zinc plated

Gasket:
    Silicone rubber

Vane:
    Stainless steel

Installation:
    Mount in any position in horizontal duct

Duct Size:
    6 in. or larger

Weight:
    1 lb., 1 oz.
