PHYSICAL DATA
Temperature Limits: 220°F (105°C). High temperature options (not U.L., C.S.A.
 or CENELEC) 400°F (205°C).
Operating Pressure: To 2000 PSIG (140KG/CM2).
Electrical Rating: U.L.: 5A @ 125/250 VAC. C.S.A. and CENELEC: 5A @ 125/250
VAC, 5A resistive, 3A inductive @ 30 VDC. MV option - gold contacts for dry
circuits rated 0.1 A @ 125 VAC. MT option - 400°F (205°C), 5A @ 125/250 VAC
(not listed).
Wiring: U.L. and C.S.A.: 18 gauge, 18" (460MM) long. CENELEC: Terminal board.
Switch Body: Lower housing (wetted part): choice of brass or stainless steel.
Upper housing: choice of brass (standard) or stainless steel.
Vane: Stainless steel.
Piping Connection: 1/2" to 2" Tee supplied with control. For 1/4" and 3/8"
pipes, use 1/2" switch and bushings.
Installation: Install with index arrow pointing in direction of flow. Mount in
 any position.
Weight: 2 to 6 lbs. (.9 to 2.7KG) depending upon construction.
Options: DPDT circuits; stainless steel upper housing, custom calibrations, OEM
 version with trimmable vane (supplied without tee).

Suggested Specification:
Automatic explosion-proof flow switches shall be vane generated to actuate a
single pole double throw snap switch. Motion of the vane shall actuate switch
by action of a magnet which controls the switch inside the one-piece sealed
switch body. Switches shall be W.E. Anderson Model No. V6 with specified
materials and pipe size.
