PHYSICAL DATA

Maximum Temperature:
 240°F (116°C)

Maximum Pressure:
 Aluminum body - 600 psig (41 bar), Brass - 3500 psig (241 bar), 304SS - 6000 psig (413 bar)

Wetted Parts *


* Body:
 Aluminum, brass, or 304 SS

* Seals:
 Buna-N or Viton®

* Magnet:
 Teflon® coated Alnico

* Other Internal Parts:
 304 SS

Accuracy:
 ±4% F.S. over entire range; ±2.5% over center 1/3 of range

Repeatability:
 1% full scale

Viscosity:
 500 SSU

Shipping Weights:
 ¼ - ½"

Models:
 2lbs. (0.9 kg)

¾ - 1" Models:
 3 ½ lbs. (1.59 kg)

1 ½" Models:
 11 lbs. (5 kg)
