PHYSICAL DATA

Output:    3-15 psig (.21 - 1.03 bar) Optional: 6-30 psig (.41 - 2.1bar)
Supply Pressure:    16 psig (1.1 bar) minimum, 100 psig (6.89 bar) maximum
Air Consumption:    Maximum 0.6 SCRM @ 100 psig (16.99/pm @ 8.89 bar)
Media Compatibility:    Clean, dry, oil free or non-combustible, non-corrosive gases
Pressure Connections:    Barbed, for " I.D. rubber or vinyl tubing
Electrical Connections:    6 screw terminal block for 14-20 AWG wire
Cable Gland:    Fits 10-25 inch (2.5-6mm) O.D. tubing
Span and Zero Adjustments:    Internal potentiometers
Weight:    12 ounces (340 grams)
Power Supply:    24 VAC, ±10% 50/60 Hz or 28 VDC
Current Consumption:    AC, 120mA max, DC, 110 mA max.
Input Signal:    4-20 mA DC (current) 1-5 VDC (voltage)
Input Impedance:    250 Ohms (4-20 mA) > 100K Ohms (1-5 VDC)
Feedback Loop:    4-20mA (0-1000 Loop resistance)
Warm Up Time:    30 minutes

PERFORMANCE AT 70°F (21.1°C)
Linearity:    ± 0.5% F.S.
Accuracy:    ± 1.5% F.S.
Hysteresis:    ± 1.5% F.S.
Repeatability:    ± 0.5% F.S.
Temperature Range:    32 to 120°F (0 to 50°C)
Thermal Errors:    ± 3% F.S. @ 120°F (50°C), ± 5% F.S. @ 32°F (0°C)
