PHYSICAL DATA
Output: 3-15 psig (.21 - 1.1 kg/cm2)
Supply Pressure: 20 psig (1.4kg/cm2) minimum, 100 psig (7.0 kg/cm2) maximum
Pressure Connections: ¼" NPTF (supply and output)
Electrical Connections: ½" NPTF conduit
Output Capacity: 4.0 scfm (1.9 1/s)
Maximum Air Consumption: 0.1 scfm (.05 1/s) @ 100 psig
Failure Mode: Upon loss of electrical signal, transducer will fall below 2 psig
Weight: 1.7 lbs, (0.77 kg)
ELECTRICAL
Input Signal: 4-20 mA
Input Impedance: 225 Ohms
PERFORMANCE
Accuracy: ± 10% of span
Repeatability: ± 0.5% of span
Linearity: ± 0.75% of span
Hysteresis: ± 0.5% of span
Temperature Range: 0° to 130°F (-17 to 55°C)
|
