PHYSICAL DATA
GENERAL
Maximum Pressure: 25 PSIG
Media Compatibility: Air & non-combustible, non-corrosive gases.

ELECTRICAL
Power Supply: 12.3 to 35 VDC
Output Signal: 4 to 20 mA DC, 2 wire (limited at 38 mA max.)
Loop Resistance: 0-1135 ohms from 12.3 to 35 VDC
Current Consumptlon: 38 mA DC (max.)

MECHANICAL
Weight: 2 lb., 8 oz.
Span and Zero adjustments: Protected potentiometers
Pressure connections: 1/8" NPT(F) high and low pressure taps

PERFORMANCE AT 70°F
Zero output: 4 mA
Full span output: 20 mA
Span: 16 mA DC
Accuracy (includes linearity, hysteresis, repeatability): ±2% of full span
output
Span and Zero: Adjustable to 0.05% of full span
Warm-up time: 10 minutes

ENVIRONMENTAL
Operating temperature: 30° to 120°F
Thermal Error: ±1 %/50°F typical

MATERIALS
Die cast aluminum case with baked dark gray hammerloid finish, acrylic cover

STANDARD ACCESSORIES
Span and zero adjust tool, mounting hardware kit
