PHYSICAL DATA
Service: Compatible gases or liquids on both pressure and reference sides.
Accuracy: ±0.1% FS .
Output: 4 to 20 mA, 2-wire.
Supply Voltage: 18 to 30 VDC.
Loop Resistance: 400Ω @ 18 VDC, 600Ω @ 24 VDC, 1000Ω @ 30 VDC.
Zero and Span: Adjustable, ±10%.
Max Overload Pressure: Ranges 1" w.c to 5 psi: 20 psi, 15 psi range: 45 psi, 30
psi range: 60 psi.
Compensated Temperature Range: 32 to 122°F (0 to 50°C).
Storage Temperature: -40 to 212°F (-40 to 100°C).
Thermal Effects: Zero: ±0.05% FS/°F, Span: ±0.05% rgd/°F..
Stability: ±1.5% FS output/year.
Wetted Parts: Brass, vinyl, glass-filled polyester, silicon and florosilicon.
Housing: Gasketed steel epoxy painted, NEMA 4.
Process Connections: Two 1/8" NPT(F).
Electrical Connections: Screw terminals, reverse polarity protected
Weight: 14 oz (937 g).
|
